ECHO 5T 15K Series
Premium Energy Storage Solution
Complete System Starting at $22,813.32
Elite Power Solution
ECHO 5T Minimum 28kWh/15kW - MAX 80kWh/30kW Series represents our flagship innovation in energy storage technology, delivering superior performance and unmatched reliability for demanding energy needs.
Premium Specifications
- 80kWh Total Capacity Per Cabinet
- 15kW Continuous Power (Max 2 15K Sol-Arks)
- Scalable up to 12 Units
- Premium Grade Hithium USA Cells
Elite Integration
- Advanced Sol-Ark Integration
- Smart Grid AI Optimization
- Multi-Mode Installation
- Enterprise BMS Technology
Premium Features
- 96.1% Round-Trip Efficiency
- Quantum AI Monitoring
- Advanced Load Prediction
- Ultra-Fast Response System
Technical Specifications
| Specification | Value | Benefit |
|---|---|---|
| System Minimum Capacity | 28kWh | Premium backup capacity |
| System MAX Capacity | 80kWh | Premium backup capacity |
| Power Output 12K | 12kW | Standard performance delivery |
| Power Output 15K | 15kW | Elite performance delivery |
| Maximum Units | 12 Units | Ultimate scalability |
| Total Potential | 960kWh/180kW | Maximum system configuration |
System Variations
| Specification | Value | Benefit |
|---|---|---|
| System Capacity | 80kWh Max Per Cabinet | Optimal home backup capacity |
| Power Output | 15kW Max 2 Mounted Exterior | High-performance delivery |
| Maximum Units | 12 Units | Extensive scalability |
| Total Potential | 960kWh/180kW | Maximum system configuration |
Expandability Options
- Base System: 28kWh/15kW
- Parallel Configuration: Up to 12 Units
- Maximum Capacity: 840kWh
- Maximum Power: 180kW
- Enterprise Scaling Technology
Investment & Value
- System Price: $22,813.32
- Initial Deposit: $500
- 33/33/34 Payment Structure
- 30% Federal Tax Credit Eligible
- State Incentives Available
The SunFusion Advantage
- 25-Year Industry-Leading Warranty
- Elite Installation Network
- 24/7 Enterprise Monitoring
- Premium Support Package
- California-Made Excellence
